User actions

initial open schema

• exception: if schema is invalid display error and abort
• populate type dropdown (will remain static throughout operation) (in same order as schema file)
• exception: if there are no entites defined in the schema warn user?
• select first item in type dropdown
• populate list with lastest entities (of current type in dropdown)
• if the list is not empty
  • select first item
  • (causing a read of that entity into right-hand panel)
• else
  • clear right-hand panel
• end if

select different type from dropdown

• (the newly selected type is displayed in dropdown)
• populate list with lastest entities (of newly selected type in dropdown)
• if the resulting list is not empty
  • select first item in the list
  • (causing a read of that entity into right-hand panel)
• else
  • clear right-hand panel
• end if

select entity from list

• read selected entity into right-hand panel

New

• (only available if a NODE is currently selected in the type dropdown, not a RELATIONSHIP)
• create new untitled node and save it to database
• (type dropdown is correctly set already)
• populate entity list around new entity and select it (causing re-read entity into right-hand panel)

Save

• update entity in database (affect changed properties only)
• (type dropdown is correctly set already)
• populate entity list around new entity and select it (causing re-read entity into right-hand panel)

Delete

• display warning dialog and allow user to cancel, otherwise...
• delete entity from database
• (type dropdown is correctly set already)
• populate entity list around former entity
• if the resulting list is not empty
  • select item modified just after the deleted item (or if that's too hard, just select the first item in the list)
  • (causing a read of that entity into right-hand panel)
• else
  • clear right-hand panel
• end if

select link from links area

• select target type in dropdown
• populate entity list around selected relationship
• select it
• (causing re-read entity into right-hand panel)

Add link

• display "choose entity" popup for user to select the other end of the relationship
• create new relationship in database
• re-read current entity into right-hand panel

Notes

•
•
•
•
